Sewage Pumps
For a full list of our pumps please browse the Sewage Pumps Category
Q(D)Y-K2 Multi-stage Submersible Pump
Performance Range
Max. Flow: 34m3/h
Max. Head: 127m
Application Limits
1. Maximum liquid temperature +40℃
2. pH level from 6.5-8.5
3. Maximum sand content is 0.1%. Passage of suspended solids up to 0.2mm
4. Power frequency is 50Hz. Nominal voltage is 220VAC for single phase and 380VAC for three phase with the range from -10% to 10%.
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
Due to multi-stage structure, Q(D)Y-K2 series pumps with high pressure are widely applied in many fields, such as agricultural irrigation, sprinkler irrigation, garden irrigation, water supply for wells, reservoirs, aquaculture, etc.
Features
1. Oiled well pump motor structure, portable and durable.
2. The impeller and flow components are made of engineering plastics which apply to use in seawater.
3. High head, multistage centrifugal pump.
Application Fields
Due to multi-stage structure, Q(D)Y-K2 series pumps with high pressure are widely applied in many fields, such as agricultural irrigation, sprinkler irrigation, garden irrigation, water supply for wells, reservoirs, aquaculture, etc.
Features
1. Oiled well pump motor structure, portable and durable.
2. The impeller and flow components are made of engineering plastics which apply to use in seawater.
3. High head, multistage centrifugal pump.
QD Multi-stage Submersible Pump
Performance Range
Max. Flow: 31m3/h
Max. Head: 120m
Application Limits
1. Maximum liquid temperature +40℃
2. pH level from 6.5-8.5
3. Maximum sand content is 0.1%. Passage of suspended solids up to 0.2mm
4. Power frequency is 50Hz. Nominal voltage is 220VAC for single phase and 380VAC for three phase with the range from -10% to 10%.
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
Due to multi-stage structure, Q(D) series pumps with high pressure are widely applied in many fields, such as agricultural irrigation, sprinkler irrigation, garden irrigation, water supply for wells, reservoirs, aquaculture, etc.
Features
1. High head, multistage centrifugal pump
2. Compact structure, covering small area, convenient to move and use
3. The angular contact ball bearing, improving the service life
Optional Available On Request
Other voltage or frequency is 60Hz
Application Fields
Due to multi-stage structure, Q(D) series pumps with high pressure are widely applied in many fields, such as agricultural irrigation, sprinkler irrigation, garden irrigation, water supply for wells, reservoirs, aquaculture, etc.
Features
1. High head, multistage centrifugal pump
2. Compact structure, covering small area, convenient to move and use
3. The angular contact ball bearing, improving the service life
Optional Available On Request
Other voltage or frequency is 60Hz
QDX-K1 Submersible Drainage Pump
Performance Range
Max. Flow: 68m3/h
Max. Head: 33m
Application Limits
1. Maximum liquid temperature +40℃
2. pH level from 6.5-8.5
3. Maximum sand content is 0.1%. Passage of suspended solids up to 0.2mm
4. Power frequency is 50Hz. Nominal voltage is 220VAC for single phase and 380VAC for three phase with the range from -10% to 10%.
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
1. Suitable for transferring water without abrasive particles
2. Suitable for well water lifting, farm irrigation, garden irrigation and living water supply
3. Suitable for industrial water eliminating, construction water supply and drainage, breeding industry water supply and drainage, etc.
Features
1. New industrial design, lower motor temperature rise.
2. Optimized motor design, improved efficiency.
3. Alloy impeller of high performance engineering plastics or aluminum.
Optional Available On Request
Other voltage or frequency is 60Hz
Application Fields
1. Suitable for transferring water without abrasive particles
2. Suitable for well water lifting, farm irrigation, garden irrigation and living water supply
3. Suitable for industrial water eliminating, construction water supply and drainage, breeding industry water supply and drainage, etc.
Features
1. New industrial design, lower motor temperature rise.
2. Optimized motor design, improved efficiency.
3. Alloy impeller of high performance engineering plastics or aluminum.
Optional Available On Request
Other voltage or frequency is 60Hz
QDX-L Submersible Drainage Pump
Performance Range
Max. Flow: 61m3/h
Max. Head: 33m
Application Limits
1. Maximum liquid temperature +40℃
2. pH level from 6.5-8.5
3. Maximum sand content is 0.1%. Passage of suspended solids up to 0.2mm
4. Power frequency is 50Hz. Nominal voltage is 220VAC for single phase and 380VAC for three phase with the range from -10% to 10%.
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
With small size and light weight, the Q(D)X-L series pump is especially suitable for the rural wells water pumping, farmland irrigation and drainage, garden watering, water spraying and family households, as well as other applications such as industrial , construction, aquaculture, fish ponds, etc.
Features
1. New-designed motor structure, longer service life.
2. Portable and durable aluminum alloy structure.
3. Alloy impeller of high performance engineering plastics or aluminum.
Optional Available On Request
1. The stainless steel bottom cover
2. Single-phase could with floater switch
3. Other voltage or frequency is 60Hz
Application Fields
With small size and light weight, the Q(D)X-L series pump is especially suitable for the rural wells water pumping, farmland irrigation and drainage, garden watering, water spraying and family households, as well as other applications such as industrial , construction, aquaculture, fish ponds, etc.
Features
1. New-designed motor structure, longer service life.
2. Portable and durable aluminum alloy structure.
3. Alloy impeller of high performance engineering plastics or aluminum.
Optional Available On Request
1. The stainless steel bottom cover
2. Single-phase could with floater switch
3. Other voltage or frequency is 60Hz
QDX-T Submersible Drainage Pump
Performance Range
Max. Flow: 44m3/h
Max. Head: 33m
Application Limits
1. Installing depth up to 5m
2. Liquid temperature up to +40℃
3. pH level from 6.5-8.5
4. Maximum sand content is 0.1%. Passage of suspended solids up to 0.2mm
Certificate
Application Fields
1. Suitable for transferring water without abrasive particles
2. Suitable for well water lifting, farm irrigation, garden irrigation and living water supply
3. Suitable for industrial water eliminating, construction water supply and drainage, breeding industry water supply and drainage, etc.
Features
1. New appearance design, high quality life
2. Anti-overloading motor design, not easy to burn machine
3. Lightweight design, easy to maintenance;
4. water from the bottom, extracting a lower water level;
5. Adopt PPOG20 plastic impeller, durable;
6. Stainless steel screws, easy to maintain;
Optional Available On Request
Other voltage or frequency is 60Hz
Application Fields
1. Suitable for transferring water without abrasive particles
2. Suitable for well water lifting, farm irrigation, garden irrigation and living water supply
3. Suitable for industrial water eliminating, construction water supply and drainage, breeding industry water supply and drainage, etc.
Features
1. New appearance design, high quality life
2. Anti-overloading motor design, not easy to burn machine
3. Lightweight design, easy to maintenance;
4. water from the bottom, extracting a lower water level;
5. Adopt PPOG20 plastic impeller, durable;
6. Stainless steel screws, easy to maintain;
Optional Available On Request
Other voltage or frequency is 60Hz
QT Peripheral Pump
Performance Range
Max. Flow: 12m3/h
Max. Head: 16.5m
Application Limits
1. Maximum liquid temperature +40℃
2. Maximum liquid density 1.2×103kg/m3
3. Power frequency is 50Hz. Nominal voltage is 220VAC for single-phase with the range from -10% to 10%.
4. Immersion depth from 0.5m-5m
5. Solids handling 7mm
Certificate
Application Fields
With small size and light weight, the QT(50Hz) series pump is especially suitable for the rural wells water pumping, farmland irrigation and drainage, garden watering, water spraying and family households, as well as other applications such as industrial , construction, aquaculture, fish ponds, etc.
Features
1. Household oil-filled type sewage pumps.
2. Much durable for the cast iron pump body and impeller.
3. 2 inch thread outlet which is suitable for all kinds of installations.
4. Sound flowing ability.
Optional Available On Request
Other voltage or frequency is 60Hz
Application Fields
With small size and light weight, the QT(50Hz) series pump is especially suitable for the rural wells water pumping, farmland irrigation and drainage, garden watering, water spraying and family households, as well as other applications such as industrial , construction, aquaculture, fish ponds, etc.
Features
1. Household oil-filled type sewage pumps.
2. Much durable for the cast iron pump body and impeller.
3. 2 inch thread outlet which is suitable for all kinds of installations.
4. Sound flowing ability.
Optional Available On Request
Other voltage or frequency is 60Hz
QY Multi-stage Submersible Pump
Performance Range
Max. Flow: 360m3/h
Max. Head: 190m
Application Limits
1. Maximum liquid temperature +40℃
2. pH level from 6.5-8.5
3. Maximum sand content is 0.1%.Passage of suspended solids up to 0.2mm
4. Power frequency is 50Hz.Nominal voltage is 380VAC for three phase with the range from -10% to 10%
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
Due to multi-stage structure, QY-L1/L2 series pumps with high pressure are widely applied in many fields, such as agricultural irrigation, sprinkler irrigation, garden irrigation, water supply for wells or reservoirs, aquaculture, etc.
Features
1. Wear-resistant whole cast iron parts design.
2. Compact structure, easy to use.
3. High quality double sides mechanical sealing to be reliable operating.
Application Fields
Due to multi-stage structure, QY-L1/L2 series pumps with high pressure are widely applied in many fields, such as agricultural irrigation, sprinkler irrigation, garden irrigation, water supply for wells or reservoirs, aquaculture, etc.
Features
1. Wear-resistant whole cast iron parts design.
2. Compact structure, easy to use.
3. High quality double sides mechanical sealing to be reliable operating.
WQ Multi-stage Submersible Sewage Pump
Performance Range
Max. Flow: 63m3/h
Max. Head: 44m
Application Limits
1. Maximum liquid temperature +40℃
2. pH level from 4-10
3. Maximum liquid density 1.2×103kg/m3
4. Voltage fluctuation range ±10%
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
WQ(Single stage with high power) series pumps are widely applied in industry, agriculture, mining, construction, municipal, environmental protection, etc. They are suitable for draining water containing particles such as short fibers, paper scraps, etc. and soft solid, such as muddy water, dirty water, domestic wastewater, sewage, manure, etc. They are ideal equipment for agricultural irrigation and drainage, pool silt cleaning and site construction, but do not apply to the location with explosion-proof requirements.
Features
1. Large power submersible sewage pump, the standard flange outlet.
2. Double channel impeller, good flowing capacity, excellent hydraulic performance.
3. Stainless steel shaft extension and carbide double side mechanical sealing.
Optional Available on Request
Other voltage or frequency is 60Hz
Application Fields
WQ(Single stage with high power) series pumps are widely applied in industry, agriculture, mining, construction, municipal, environmental protection, etc. They are suitable for draining water containing particles such as short fibers, paper scraps, etc. and soft solid, such as muddy water, dirty water, domestic wastewater, sewage, manure, etc. They are ideal equipment for agricultural irrigation and drainage, pool silt cleaning and site construction, but do not apply to the location with explosion-proof requirements.
Features
1. Large power submersible sewage pump, the standard flange outlet.
2. Double channel impeller, good flowing capacity, excellent hydraulic performance.
3. Stainless steel shaft extension and carbide double side mechanical sealing.
Optional Available on Request
Other voltage or frequency is 60Hz
WQ-QG Grinder Pump
Performance Range
Max. Flow: 20m3/h
Max. Head: 28
Application Limits
1. Maximum liquid temperature +40℃
2. pH level from 4-10
3. Maximum liquid density 1.2×103kg/m3
4. Power frequency is 50Hz. Nominal voltage is 220VAC for single phase and 380VACfor three phase with the range from -10% to 10%.
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
Suitable for pumping domestic wastewater, draining industrial wastewater, digester sewage, aquaculture sewage, etc.
Features
1. The half-opening impeller of wear-resisting material QT450-10, the pump body and motor bracket are all durable for cast iron material.
2. With 95 cr18 (SUS440C) cutting knife which can cut up the objects.
3. Stainless steel shaft extension, carbide double-side mechanical sealing.
Optional Available on Request
Other voltage or frequency is 60Hz
Application Fields
Suitable for pumping domestic wastewater, draining industrial wastewater, digester sewage, aquaculture sewage, etc.
Features
1. The half-opening impeller of wear-resisting material QT450-10, the pump body and motor bracket are all durable for cast iron material.
2. With 95 cr18 (SUS440C) cutting knife which can cut up the objects.
3. Stainless steel shaft extension, carbide double-side mechanical sealing.
Optional Available on Request
Other voltage or frequency is 60Hz
WQ(D) Multi-stage Submersible Sewage Pump
Performance Range
Max. Flow: 140m3/h
Max. Head: 44m
Application Limits
1. Maximum liquid temperature +40℃
2. pH level from 4-10
3. Maximum liquid density 1.2×103kg/m3
4. Power frequency is 50Hz. Nominal voltage is 220VAC for single phase and 380VAC or 415VAC for three phase with the range from -10% to 10%.
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
WQ(D) series pumps are widely applied in industry, agriculture, mining, construction, municipal, environmental protection, etc. They are suitable for draining water containing particles such as short fibers, paper scraps, etc. and soft solid, such as muddy water, dirty water, domestic wastewater, sewage, manure, etc. They are ideal equipment for agricultural irrigation and drainage, pool silt cleaning and site construction, but do not apply to the location with explosion-proof requirements.
Features
1. Wear-resistant whole cast iron parts design
2. Double channel impeller, good flow capacity, excellent hydraulic performance
3. The stainless steel shaft extension, carbide double sides mechanical sealing
Optional Available on Request
Other voltage or frequency is 60Hz
Application Fields
WQ(D) series pumps are widely applied in industry, agriculture, mining, construction, municipal, environmental protection, etc. They are suitable for draining water containing particles such as short fibers, paper scraps, etc. and soft solid, such as muddy water, dirty water, domestic wastewater, sewage, manure, etc. They are ideal equipment for agricultural irrigation and drainage, pool silt cleaning and site construction, but do not apply to the location with explosion-proof requirements.
Features
1. Wear-resistant whole cast iron parts design
2. Double channel impeller, good flow capacity, excellent hydraulic performance
3. The stainless steel shaft extension, carbide double sides mechanical sealing
Optional Available on Request
Other voltage or frequency is 60Hz
WQ(D)-H1 Submersible Sewage Pump
Performance Range
Max. Flow: 62m3/h
Max. Head: 29m
Application Limits
1. Ambient temperature: 0~40℃; maximum liquid temperature +40℃
2. pH level from 4-10
3. Maximum liquid density 1.2×103kg/m3
4. Power frequency is 50Hz.Nominal voltage is 220VAC for single phase and 380VACfor three phase with the range from -10% to 10%.
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
WQ(D)-H1 series pumps are widely applied in industry, agriculture, construction, municipal, environmental protection, etc. They are suitable for draining water containing particles such as short fibers, paper scraps, etc. and soft solid, such as muddy water, dirty water, domestic wastewater, sewage, manure, etc. They are ideal equipment for agricultural irrigation and drainage, pool silt cleaning and site construction.
Features
1. Insulation class: F.
2. The wear-resistant impeller of QT450-10 material.
3. Stainless steel shaft extension, carbide double-sides mechanical sealing.
4. Double channel impeller, good flow capacity, excellent hydraulic performance.
Application Fields
WQ(D)-H1 series pumps are widely applied in industry, agriculture, construction, municipal, environmental protection, etc. They are suitable for draining water containing particles such as short fibers, paper scraps, etc. and soft solid, such as muddy water, dirty water, domestic wastewater, sewage, manure, etc. They are ideal equipment for agricultural irrigation and drainage, pool silt cleaning and site construction.
Features
1. Insulation class: F.
2. The wear-resistant impeller of QT450-10 material.
3. Stainless steel shaft extension, carbide double-sides mechanical sealing.
4. Double channel impeller, good flow capacity, excellent hydraulic performance.
WQ(D)-L1 Submersible Sewage Pump
Performance Range
Max. Flow: 149m3/h
Max. Head: 44m
Application limits
1. Maximum liquid temperature +40℃
2. pH level from 4-10
3. Maximum liquid density 1.2×103kg/m3
4. Power frequency is 50Hz. Nominal voltage is 220VAC for single phase and 380VACfor three phase with the range from -10% to 10%.
5. Immersion depth from 0.5m-5m
Certificate
Application Fields
WQ(D)-L1 series pumps are widely applied in industry, agriculture, mining, construction, municipal, environmental protection, etc. They are suitable for draining water containing particles such as short fibers, paper scraps, etc. and soft solid, such as muddy water, dirty water, domestic wastewater, sewage, manure, etc. They are ideal equipment for agricultural irrigation and drainage, pool silt cleaning and site construction, but do not apply to the location with explosion-proof Requirements.
Features
1. The whole cast iron design, wear-resistant, durable and nice appearance.
2. Double channel impeller, good flow capacity, excellent hydraulic performance.
3. Stainless steel shaft extension, carbide double-side mechanical sealing.
Application Fields
WQ(D)-L1 series pumps are widely applied in industry, agriculture, mining, construction, municipal, environmental protection, etc. They are suitable for draining water containing particles such as short fibers, paper scraps, etc. and soft solid, such as muddy water, dirty water, domestic wastewater, sewage, manure, etc. They are ideal equipment for agricultural irrigation and drainage, pool silt cleaning and site construction, but do not apply to the location with explosion-proof Requirements.
Features
1. The whole cast iron design, wear-resistant, durable and nice appearance.
2. Double channel impeller, good flow capacity, excellent hydraulic performance.
3. Stainless steel shaft extension, carbide double-side mechanical sealing.
WE HAVE GOT A WIDE VARIETY OF
Submersible Pumps
All Supplied at competitive prices
3.5SE(m) 3.5’’ Deep Well Pump
Performance Range
Max. Flow: 7.2m3/h
Max. Head: 169m Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content (in mass fraction) up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.Certificate
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.Features
1. Edible oil filled motor, stable & reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Available with cable with a motor plug, disassemble conveniently;
4. Available with pump casing with plug, integrated stage floating impellers;
5. Installation in 3.5" or larger boreholes;Optional Available On Request
NO
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.Features
1. Edible oil filled motor, stable & reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Available with cable with a motor plug, disassemble conveniently;
4. Available with pump casing with plug, integrated stage floating impellers;
5. Installation in 3.5" or larger boreholes;Optional Available On Request
NO
3.5SG(m) 3.5’’ Deep Well Pump
Performance Range
Max. Flow: 6.0m3/h
Max. Head: 186m Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.
Certificate
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Motor equipped with start box which is built in capacitor & current mode thermal protector, convenient for replacement;
3. Pump sleeve with screw thread, single stage floating impellers;
4. Installation in 3.5" or larger boreholes;
Optional Available On Request
No
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Motor equipped with start box which is built in capacitor & current mode thermal protector, convenient for replacement;
3. Pump sleeve with screw thread, single stage floating impellers;
4. Installation in 3.5" or larger boreholes;
Optional Available On Request
No
3SE(m) 3’’ Deep Well Pump
Performance Range
Max. Flow: 3.6m3/h
Max. Head: 142m
Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content (in mass fraction) up to 0.01%;
3. Hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.
Certificate
Application Fields
1. Building/construction work/Domestic water supply;
2. Irrigation and Small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable & reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor & thermal mode protector;
3. Available with pump casing with plug, single stage floating impellers;
4. Installation in 3" or larger boreholes.
Optional available on request
Discharge chamber, Inlet parts are available with Brass or Stainless steel 304.
3SG(m) 3’’ Deep Well Pump
Performance Range
Max. Flow: 3.6m3/h
Max. Head: 142m Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content (in mass fraction) up to 0.01%;
3. Hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.
Certificate
Application Fields
1. Building/construction work/Domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor equipped with start box which is built in capacitor ¤t mode thermal protector, convenient for replacement;
3. Pump sleeve with screw thread, single stage floating impellers;
4. Installation in 3" or larger boreholes.
Optional Available On Request
Oil chamber is available with Brass or SS304; Discharge chamber, Inlet parts are available with Casting or SS304.
Application Fields
1. Building/construction work/Domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor equipped with start box which is built in capacitor ¤t mode thermal protector, convenient for replacement;
3. Pump sleeve with screw thread, single stage floating impellers;
4. Installation in 3" or larger boreholes.
Optional Available On Request
Oil chamber is available with Brass or SS304; Discharge chamber, Inlet parts are available with Casting or SS304.
4SE(m) 4’’ Deep Well Pump
Performance Range
Max. Flow: 22m3/h
Max. Head: 480m
Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.
Certificate
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Available with cable with a motor plug, disassemble conveniently;
4. Available with pump casing with plug, 2~8 m3/hrs series with single stage floating impellers, 10~16m3/hrs series with integrated stage floating impellers;
5. Installation in 4" or larger boreholes;
Optional Available On Request
Oil chamber is available with brass or SS304; Discharge chamber, Inlet parts are available SS304.
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Available with cable with a motor plug, disassemble conveniently;
4. Available with pump casing with plug, 2~8 m3/hrs series with single stage floating impellers, 10~16m3/hrs series with integrated stage floating impellers;
5. Installation in 4" or larger boreholes;
Optional Available On Request
Oil chamber is available with brass or SS304; Discharge chamber, Inlet parts are available SS304.
4SG(m) 4’’ Deep Well Pump
Performance Range
Max. Flow: 22m3/h
Max. Head: 454m
Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.Certificate
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1.Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2.Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3.Available with cable with a motor plug, disassemble conveniently;
4.Available with pump casing with plug, 2~8 m3/hrs series with single stage floating impellers, 10~16m3/hrs series with integrated stage floating impellers;
5.Installation in 4" or larger boreholes;
Optional Available On Request
Oil chamber is available with brass or SS304; Discharge chamber, Inlet parts are available with casting.
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1.Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2.Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3.Available with cable with a motor plug, disassemble conveniently;
4.Available with pump casing with plug, 2~8 m3/hrs series with single stage floating impellers, 10~16m3/hrs series with integrated stage floating impellers;
5.Installation in 4" or larger boreholes;
Optional Available On Request
Oil chamber is available with brass or SS304; Discharge chamber, Inlet parts are available with casting.
4SS 4’’ Deep Well Pump
Performance Range
Max. Flow: 10.8m3/h
Max. Head: 330m
Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.Certificate Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor equipped with start box which built in capacitor ¤t mode thermal protector, convenient for replacement;
3. Available with stainless steel pump head, effective against the corrosion and abrasive wear;
4. Installation in 4" or larger boreholes.
Optional Available On Request
Pipe connection of discharge chamber is available with 1.25", 1.5", 2".
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor equipped with start box which built in capacitor ¤t mode thermal protector, convenient for replacement;
3. Available with stainless steel pump head, effective against the corrosion and abrasive wear;
4. Installation in 4" or larger boreholes.
Optional Available On Request
Pipe connection of discharge chamber is available with 1.25", 1.5", 2".
6SE 6’’ Deep Well Pump
Performance Range
Max. Flow: 60m3/h
Max. Head: 448m Application Limits 1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.Certificate Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Available with pump casing with plug, integrated stage floating impellers;
3. Installation in 6" or larger boreholes.
Optional Available On Request
No
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Available with pump casing with plug, integrated stage floating impellers;
3. Installation in 6" or larger boreholes.
Optional Available On Request
No
6SS 6’’ Deep Well Pump
Performance Range
Max. Flow: 78m3/h
Max. Head: 283m Application Limits 1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.
Certificate
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Available with stainless steel pump head, effective against the corrosion and abrasive wear;
2. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
3. Available with controller box, bring about general protection;
4. Installation in 6" or larger boreholes.
Optional Available On
chamber is available with 3"or 4"
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Available with stainless steel pump head, effective against the corrosion and abrasive wear;
2. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
3. Available with controller box, bring about general protection;
4. Installation in 6" or larger boreholes.
Optional Available On
chamber is available with 3"or 4"
NK(m) 5’’ Submersible Pump
Performance Range
Max. Flow: 5.4m3/h
Max. Head: 88m
Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.
Certificate
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Single phase motor equipped with start box which is built in capacitor ¤t mode thermal protector, convenient for replacement;
2. Built-in motor, the suction pump body
3. Installation in 5" or larger boreholes.
Optional Available On Request
Impeller is available with stainless steel 304
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Single phase motor equipped with start box which is built in capacitor ¤t mode thermal protector, convenient for replacement;
2. Built-in motor, the suction pump body
3. Installation in 5" or larger boreholes.
Optional Available On Request
Impeller is available with stainless steel 304
QGY(D) 4’’ Screw Pump
Performance Range
Max. Flow: 2.4m3/h
Max. Head: 163m
Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.Certificate Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable & reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Owned intellectual property of rubber stator, effective against the influence of thermal shock;
4. Installation in 4" or larger boreholes;
Optional Available On Request
No
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable & reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Owned intellectual property of rubber stator, effective against the influence of thermal shock;
4. Installation in 4" or larger boreholes;
Optional Available On Request
No
QJD 4’’ Deep Well Pump
Performance Range
Max. Flow: 4.8m3/h
Max. Head: 119m
Application Limits
1. Max. ambient temperature< 40℃;
2. Sand content (in mass fraction) up to 0.01%;
3. Hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 20m below the static water table.
Certificate
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Treble seal shield for excellent sand prevention;
2. High efficiency and lower power consumption;
3. Single phase motor with built in capacitor & thermal mode protector;
4. Pump sleeve with screw thread, single stage floating impellers;
5. Installation in 4" or larger boreholes;
Optional Available On Request
No
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Treble seal shield for excellent sand prevention;
2. High efficiency and lower power consumption;
3. Single phase motor with built in capacitor & thermal mode protector;
4. Pump sleeve with screw thread, single stage floating impellers;
5. Installation in 4" or larger boreholes;
Optional Available On Request
No
SEE OUR COLLECTION OF
PV Modules / Solar Panels
Low & High Voltage Electric Products
H-Class Impregnated Insulated Dry-type Transformer
Application: for power distribution system and industrial enterprises, etc.
Standards: IEC 60076-11
Parameters: Rated Voltage: 10kV.
Rated Capacity: 200-2500kVA.
Features: 1.High security and reliability in operation.
2.Economic and efficient to reduce network loss and working cost.
3.Low noise.
4.Low partial discharge.
5.Operation in moist place with high moisture-proof capability.
6.Customized transformers are available on your requirement.
Epoxy Resin Cast Dry-type Transformer
Application: for power distribution system and large industrial enterprises, etc.
Standards: IEC 60076-11
Parameters: Rated Voltage: 10kV-35kV.
Rated Capacity: 30-20000kVA.
Features: 1.High security and reliability in operation.
2.Economic and efficient to reduce network loss and working cost.
3.Low temperature rise.
4.Low noise.
5.Operation in moist place with high moisture-proof capability.
6.Customized transformers are available on your requirement.
Amorphous Alloy Core Dry-type Transformer
Application: applicable for all places where common dry-type transformers are used, such as high-rise buildings, commercial centers, airports, oil platforms, subways, tunnels, airports, railway stations, industrial and mining enterprises and power plants. It is especially suitable for places which are flammable and explosive.
Standards: IEC 60076-11
Parameters: Rated capacity: 30-2500kVA
HV rated voltage: 10kV
Features: 1.High safety and reliability, non-pollution, can directly run in the load center.
2. High mechanical strength, high resistance to short-circuit, low partial discharge, high thermal stability and long life.
3. Low no-load loss, high efficiency and low noise.
4. Good thermal performance, high running capability. It can increase the capacity to run during forced air cooling.
5. Good moisture performance, fire-retardant, explosion prevention and maintenance-free.
6. Small size, light weight.
Distribution Transformer (up tp 35kV)
Application: For distribution substation
Standards: IEC 60076-1, IEC 60076-2, IEC 60076-3, IEC60076-4, IEC60076-5
Parameters: 50/60Hz up to 35kV 50-75000kVA
Features: High security, strong fire resistance.
High mechanical strength and short circuit resistance, good thermal stability, high reliability, long service life.
Good moisture resistance, which can meet the special requirements of metallurgical and petrochemical systems and wet
and dirty areas.
Small size, light weight, easy to transport.
220kV Power Transformer
Application: suitable for power plant, substation, large-scale industrial etc.
Standards: IEC 60076-1, IEC 60076-2, IEC 60076-3, IEC 60076-5; ANSI, IEEE, AS, etc.
Parameters: Voltage range: 50/60Hz 220kV.
Capacity range: 31500kVA-360000kVA.
Features: 1.High security and reliability in operation.
2.Economic and efficient to reduce network loss and operation cost.
3.High short circuit strength and insulating strength.
4.Compact design, Low-noise and light in weight.
5.Customized transformers are available on your requirement.
6.Competitive short delivery time.
330-750kV Power Transformer
Application: For power station, transformer substation, and industrial enterprises, etc..
Standards: IEC 60076-1, IEC 60076-2, IEC 60076-3, IEC 60076-5; ANSI, IEEE, AS, VEIKI, EN, etc.
Parameters: Rated Voltage: up to 750kV
Capacity: up to 1200MVA (Three phases)
Capacity: up to 400MVA (Single phase)
High security and reliability Features: in operation.
Economic and efficient to reduce network loss and operation cost.
High short circuit strength and insulating strength.
Compact design, Low noise and light in weight.
Customized transformers are available on your requirement.
Competitive short delivery time.
110kV Power Transformer
Application: suitable for power plant, substation, large-scale industrial etc.
Standards: IEC 60076-1, IEC 60076-2, IEC 60076-3, IEC 60076-5; ANSI, IEEE, AS, etc.
Parameters: Voltage range: 50/60Hz 110kV.
Capacity range: 6300kVA-120000kVA.
Features: 1.High security and reliability in operation.
2.Economic and efficient to reduce network loss and operation cost.
3.High short circuit strength and insulating strength.
4.Compact design, Low-noise and light in weight.
5.Customized transformers are available on your requirement.
6.Competitive short delivery time.
Reactor
Application: It is suitable for substation and power plant, which is parallel connection in power system. It is mainly used to compensate capacitor current, reduce transmission lossand suppress the lift and capacitive operation of light load, improve system stability and prevent abnormal voltage generation.
Standards: IEC 60076-6
Parameters: up to 500kV
Features: Low-noise.
Low losses.
Compact structure.
145kV Compact Gas Insulated Switchgear(GIS)
Application: For power substations, especially substations in city center, contaminated region and also hydropower stations.
Standards: IEC 62271-203
Parameters: Rated voltage: 126,145kV.
Rated current: 2500, 3150A.
Rated breaking current, 3s: 40kA.
Features: 1.KEMA under testing.
2.Miniaturized design.
3.High insulation reliability.
4.Good breaking capacity for the circuit breakers.
5.Low noise during the operation without oil and gas.
6.Meet various requirements of clients by modular design.
7.Both single-pole and three-pole operation applicable.
8.High anti-seismic capability.
9.High operation reliability, therefore less maintenance is needed.
252kV Gas Insulated Switchgear(GIS)
Application: For power substations, especially substations in city center, contaminated region and also hydropower stations.
Standards: IEC 62271-203
Parameters: Rated voltage: 252kV.
Rated current: 2000-4000A.
Rated breaking current, 3s: 50kA.
Features: 1.Compact design, three phases Busbar in common tank, save installation area.
2.Rated breaking current 50kA for the circuit breakers.
3.High operation reliability, less maintenance.
4.High anti-seismic capability.
5.Meet customer requirements by modular design.
LW43A-252 SF6 Circuit Breaker
Application: For control and protection 220 kV power system.
Standards: IEC 62271-100
Parameters: Rated voltage: 252kV.
Rated current: 4000A.
Rated short-circuit breaking current: 50kA.
Features: 1.High breaking capacity.
2.Reliable insulation performance.
3.Low noise, without leakage of oil and gas.
4.Easy installation and adjustment. Less maintenance.
5.Long service life.
