1.1 Function protection of circuits against short-circuit currents,protection of circuits against overload currents,switch,isolation. 1.2 Selection Technical data of the network at the point considered:the earthing systems (TNS, TNC),short-circuit current at the circuit-breaker installation point,  which must always be less than the breaking capacity of this device,network normal voltage. 1.3 Approvals and certificates Detailed information, please refer to Certificates Table on the last page. CATALOG DZ158 Moulded Case Circuit Breaker(DC type)

1.1 Function protection of circuits against short-circuit currents,protection of circuits against overload currents,switch,isolation. 1.2 Selection Technical data of the network at the point considered:the earthing systems (TNS, TNC),short-circuit current at the circuit-breaker installation point,  which must always be less than the breaking capacity of this device,network normal voltage. Tripping curves: B curve (3-5In) protection for people and big length cables in TN and IT systems. C curve (5-10In) protection for resistive and inductive loads with low inrushcurrent. D curve(10-20In) protection for circuits which supply loads with high inrush current at the circuit closing (LV/LV transformers, breakdown lamps). 1.3 Approvals and certificates Detailed information, please refer to Certificates Table on the last page. CATALOG eB Miniature Circuit Breaker PDF

Overload protection, short circuit protection and isolation. It is widely used in building power distribution, industrial power distribution, as well as control and protection for a variety of equipment with operating current not exceeding 125A. CATALOGUE: NXB-63 Miniature circuit breaker PDF

Rated current: 63, 80, 100(1P, 2P, 3P, 4P), 125(1P, 2P); Rated voltage: 240V ~ (1P), 415V ~ (2P, 3P, 4P); Frequency: 50Hz; Electromagnetic release type: B, C, D; Number of poles: 1P, 2P, 3P, 4P; Mechanical life: 20000 cycles; Electrical life: 6000 cycles (In≤100A); 4000 cycles (In＞100A); Rated short-circuit breaking capacity(Icn): 10000A; Short-circuit breaking capacity(Ics): 7500A; Rated impulse withstand voltage(Uimp): 4kV; CATALOG NXB-125G Miniature Circuit Breaker PDF
