LZZBW77-10 Outdoor Current Transformer

1.1 Function Personnel and fire protection Cable and line protection against overload and short-circuits. 1.2 Selection I∆n ≤ 30 mA: additional protection in the case of direct contact. I∆n ≤300 mA: preventative fire protection in the case of ground fault currents. AC class – Tripping is ensured for sinusoidal,alternating currents, whether they be quickly applied or slowly increase. 1.3 Approvals and certificates CATALOG DZ158LE Residual Current Operated Circuit Breaker PDF

1.1 Function Personnel and fire protection: Cable and line protection against overload and short-circuits. 1.2 Selection Rated residual operating current I∆n ＝30 mA: additional protection in the case of direct contact. Tripping class A and AC class A class tripping is ensured for sinusoidal, alternating residual currents as well as for pulsed DC residual currents, whether they be quickly or slowly increase. AC class tripping is ensured for sinusoidal, alternating residual currents, whether they be quickly or slowly increase. Tripping curve B curve (3 In-5 In) protection and control of the circuits against  overloads and short-circuits; protection for people and big length cables in TN and IT systems. C curve (5  In-10 In) protection and control of the circuits against overloads and short-circuits; protection for resistive and inductive loads with low inrush current. 1.3 Approvals and certificates CE/CB/KEMA 1.4 Add-on devices XF9 auxiliary contacts S9 shunt release V9 under voltage release OVT-1 over voltage release CATALOG NB310L(3PN) Residual Current Operated Circuit Breaker with over-current protection PDF
