Performance Curve
Applications Fields
1. Suitable for transferring water without abrasive particles or other liquid whose properties are similar to water.
2. Widely used in vegetable greenhouse water supply, breeding industry water supply and drainage, water tower water supply, pipeline pressurization, various corollary equipment, etc.
Features
1. Single suction centrifugal pump, with high efficiency
2. Copper impeller, stable performance
3. High head, small flow rate
Motor
1. Single-Phase 220V/50Hz
2. Mechanical seal: Ceramic/Graphite/NBR rubber
3. Motor: 2 pole asynchronous motor, copper wires, built-in thermal protector, fully closed fan cooling, continuous running
4. Protection: IP44
5. Insulation: Class B
Optional Available on Request
1. 304 stainless steel welding shaft
2. Electrophoretic pump body and connections
3. NSK bearing
4. Motor whose insulation class is F
5. Other voltage or frequency is 60Hz
Performance Range
Max. Flow: 22m3/h
Max. Head: 480m
Application Limits
1. Max. ambient temperature < 40℃;
2. Sand content(in mass fraction)up to 0.01%;
3. hydrogen sulfide content up to 1.5mg/L, chloride ion content up to 400mg/L;
4. pH 6.5 to 8.5;
5. Maximum: 70m below the static water table.
Certificate
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Available with cable with a motor plug, disassemble conveniently;
4. Available with pump casing with plug, 2~8 m3/hrs series with single stage floating impellers, 10~16m3/hrs series with integrated stage floating impellers;
5. Installation in 4" or larger boreholes;
Optional Available On Request
Oil chamber is available with brass or SS304; Discharge chamber, Inlet parts are available SS304.
Application Fields
1. Building/construction work/domestic water supply;
2. Irrigation and small water work;
3. Landscaping;
4. Water conservancy system;
5. Factory.
Features
1. Edible oil filled motor, stable& reliable running with pressure regulating membrane;
2. Single phase motor with built in B Grade oil proofed capacitor &thermal mode protector;
3. Available with cable with a motor plug, disassemble conveniently;
4. Available with pump casing with plug, 2~8 m3/hrs series with single stage floating impellers, 10~16m3/hrs series with integrated stage floating impellers;
5. Installation in 4" or larger boreholes;
Optional Available On Request
Oil chamber is available with brass or SS304; Discharge chamber, Inlet parts are available SS304.
